Customize invoice templates via API: BlockTemplate tutorial

Many invoice APIs lock you into rigid layouts: logo top-left, no discount column, no control over colors. Invoice-api.xhub goes the other way — PDF invoices are described by a JSON-based BlockTemplate. The result is versioned, diffable, and reproducible through a CI pipeline.

In this tutorial I'll show you how to build your own template in 10 minutes, embed your logo, apply brand colors via design tokens, and render VAT rows correctly — including the pitfalls around EN 16931 and ZUGFeRD.

📚 Full reference: All schemas and block types are documented in the invoice templates docs.

BlockTemplate in 30 seconds

A BlockTemplate is a JSON document with five areas:

1{
2  "version": "1.0.0",
3  "name": "my-invoice",
4  "page":   { /* page size, margins, design tokens */ },
5  "header": { /* optional letterhead — on every page */ },
6  "body":   { "blocks": [ /* the actual content */ ] },
7  "footer": { /* optional footer area */ },
8  "styles": { /* named presets */ }
9}

The body holds an array of nine block types: text, table, keyvalue, summary, image, spacer, line, qrcode, and columns. Each block shares the same envelope { type, data } — and an optional condition that hides it when its placeholder is empty.

Step 1 — Define design tokens

Instead of repeating hex values across every block, declare them once in page.colorScheme:

1{
2  "page": {
3    "size": "A4",
4    "margins": { "top": 40, "right": 40, "bottom": 40, "left": 40 },
5    "colorScheme": {
6      "primary": "#0ea5e9",
7      "text":    "#111827",
8      "muted":   "#6b7280",
9      "line":    "#e5e7eb"
10    },
11    "fontSizes": { "body": 10, "heading": 18, "small": 8 }
12  }
13}

Blocks reference them via { token: "…" }:

1{ "type": "text", "data": { "content": "INVOICE", "color": { "token": "primary" } } }

When the brand color changes, you swap a single value — the whole template follows.

Step 2 — Logo in the header

A two-column header: company name on the left, logo on the right. repeatOnAllPages: true turns it into a letterhead on every page.

1{
2  "header": {
3    "height": 90,
4    "repeatOnAllPages": true,
5    "blocks": [{
6      "type": "columns",
7      "data": {
8        "columnGap": 20,
9        "columns": [
10          { "width": "*",    "blocks": [
11            { "type": "text", "data": { "content": "{{seller.name}}", "bold": true, "fontSize": { "token": "heading" } } }
12          ]},
13          { "width": "auto", "blocks": [
14            { "type": "image", "data": { "src": "https://cdn.example.com/logo.png", "fit": [140, 70], "alignment": "right" } }
15          ]}
16        ]
17      }
18    }]
19  }
20}

The src accepts a URL, a base64 data URI, or — as here — a placeholder that is supplied per tenant from the invoice payload.

Step 3 — Line items with a discount column

The table block binds to {{items}}. Each column declares field, header, width, and optionally format: "currency" | "percent" | "number":

1{
2  "type": "table",
3  "data": {
4    "dataSource": "{{items}}",
5    "repeatHeader": true,
6    "layout": "lightHorizontalLines",
7    "headerFillColor": { "token": "primary" },
8    "headerTextColor": "#FFFFFF",
9    "columns": [
10      { "field": "articleNumber",   "header": "Art. No.",     "width": "15%" },
11      { "field": "description",     "header": "Description",  "width": "*" },
12      { "field": "quantity",        "header": "Qty",          "width": "10%", "align": "center" },
13      { "field": "unitPrice",       "header": "Unit price",   "width": "15%", "align": "right", "format": "currency" },
14      { "field": "netAmount",       "header": "Net",          "width": "15%", "align": "right", "format": "currency" }
15    ]
16  }
17}

Column widths accept pixel values, percentages, auto, or * (fills remaining space).

Step 4 — Dynamic VAT rows

This is the part many templates hard-code — and then break the moment an invoice has mixed VAT rates or reverse-charge. The summary block with dynamicRows iterates over {{taxSummary}}:

1{
2  "type": "summary",
3  "data": {
4    "alignment": "right",
5    "headerRows": [
6      { "label": "Net total", "value": "{{subtotal}}", "valueFormat": "currency" }
7    ],
8    "dynamicRows": {
9      "dataSource": "{{taxSummary}}",
10      "valueField": "taxAmount",
11      "valueFormat": "currency",
12      "labelTemplate": "VAT {{taxRate}}%"
13    },
14    "footerRows": [
15      { "label": "Total due", "value": "{{total}}", "bold": true, "valueFormat": "currency", "separator": true }
16    ]
17  }
18}

An invoice with 7% + 19% automatically renders two rows. Reverse-charge yields taxAmount: 0 plus the mandatory notice as a conditional text block.

Step 5 — Use the template

Two ways to hand your template to the API:

1. As a saved template (recommended):

1curl -X POST https://service.invoice-api.xhub.io/api/v1/invoice/de/zugferd/generate \
2  -H "Authorization: Bearer $XHUB_API_KEY" \
3  -d '{
4    "templateId": "b3c9a0d8-4f2e-4a1c-9e87-0d2f1a5b6c7d",
5    "invoice":   { /* creator payload */ }
6  }'

2. Inline — for CI tests or dynamic layouts:

1curl -X POST https://service.invoice-api.xhub.io/api/v1/invoice/de/zugferd/generate \
2  -H "Authorization: Bearer $XHUB_API_KEY" \
3  -d '{
4    "invoice": { /* ... */ },
5    "formatOptions": { "template": { /* inline BlockTemplate */ } }
6  }'

If both are provided, precedence is templateId > formatOptions.template > default.

Compliance pitfalls

Three things that are easy to miss:

1. Mandatory fields (§ 14 UStG / EN 16931). Invoice number, issue date, delivery date, VAT ID or tax number, amounts per VAT rate — none may be missing. The validator checks this on /generate, but a defensive template never drops those blocks in the first place.
2. Leitweg-ID for B2G. Invoices to German public authorities require a Leitweg-ID. In the payload it lives under countrySpecific.leitwegId (DE-specific). Using condition: "{{countrySpecific.leitwegId}}" the block renders only for B2G — the same template keeps working for B2B.
3. ZUGFeRD is not just the PDF. The BlockTemplate is the visible layer. The structured EN-16931 XML is automatically embedded into PDF/A-3 on /generate. Both views must show identical numbers — that's why both come from the same invoice payload.

The full compliance matrix covering reverse-charge, small-business scheme, and Factur-X lives in the compliance docs.

Closing thoughts

BlockTemplate is not a replacement for a design tool — it's an API-first approach for teams that treat invoices like code: versioned, reviewable, testable in CI. For one-off layout tweaks a WYSIWYG editor may be faster. For 50 tenants with distinct logos and colors rolled out through a single API call, JSON wins.

Further reading:

• Invoice templates overview — all block types at a glance
• Placeholder reference — every field from the creator payload
• Branding guide — design tokens in detail
• Cookbook — SEPA QR, page numbers, early-payment discount, …

FAQ

Do I need a separate template per tenant layout? No — one template with design tokens is enough. Per tenant, you override only page.colorScheme and the logo. For 50 tenants you keep a single template structure; only the tokens change.

Can I version BlockTemplate and test it in CI? Yes. Because the template is a JSON document, it flows through Git like code: diffs stay readable, code review works, and a CI snapshot test can hash the rendered PDF after every commit and flag unintended changes.

What's the difference between templateId and formatOptions.template? templateId references a template stored in the console or via the pdf.templateCreate tRPC mutation (recommended for stable production). formatOptions.template passes BlockTemplate JSON inline — handy for tests, CI and dynamically generated layouts. When both are provided, templateId wins.

Does BlockTemplate also work for Peppol and XRechnung — or only PDF/ZUGFeRD? BlockTemplate only controls the visual PDF layer. The structured XML for XRechnung or Peppol BIS 3.0 comes from the invoice payload. For ZUGFeRD and Factur-X the EN 16931 XML is automatically embedded into the PDF/A-3 during /generate (hybrid invoice).

Where do I find all available placeholders? In the placeholder reference. Every field from the creator payload is available as a {{mustache}} placeholder — from {{invoiceNumber}} through {{seller.bankAccount.iban}} to {{countrySpecific.leitwegId}}.
